Koormuslüliti 3P, 160A
| Pikkus (mm) | 150 |
| Laius (mm) | 140 |
| Kõrgus (mm) | 165 |
| Version as main switch | Jah |
| Version as maintenance-/service switch | Jah |
| Version as safety switch | Jah |
| Version as emergency stop installation | Ei |
| Version as reversing switch | Ei |
| Number of switches | 1 |
| Max. rated operation voltage Ue AC | 415 V |
| Rated operating voltage | 380 V |
| Rated operating voltage | 415 V |
| Rated permanent current Iu | 160 A |
| Rated permanent current at AC-23, 400 V | 160 A |
| Rated permanent current at AC-21, 400 V | 160 A |
| Rated short-time withstand current lcw | 7 kA |
| Rated operation power at AC-23, 400 V | 72 kW |
| Switching power at 400 V | 105 kW |
| Conditioned rated short-circuit current Iq | 50 kA |
| Number of poles | 3 |
| Motor drive optional | Ei |
| Motor drive integrated | Ei |
| Voltage release optional | Ei |
| Device construction | Built-in device fixed built-in technique |
| Suitable for floor mounting | Jah |
| Suitable for front mounting 4-hole | Ei |
| Suitable for front mounting centre | Ei |
| Suitable for distribution board installation | Jah |
| Suitable for intermediate mounting | Ei |
| Colour control element | Black |
| Interlockable | Jah |
| Degree of protection (IP), front side | IP00 |
| Pakendi suurus 1 (MOQ) | 1 |
| Pakendi suurus 1 pikkus (mm) | 105 |
| Pakendi suurus 1 laius (mm) | 150 |
| Pakendi suurus 1 kõrgus (mm) | 180 |
| Pakendi suurus 1 brutokaal (kg) | 1.17 |
| Pakendi suurus 2 (pakk) | 6 |
| Pakendi suurus 2 pikkus (mm) | 180 |
| Pakendi suurus 2 laius (mm) | 148 |
| Pakendi suurus 2 kõrgus (mm) | 92 |
| Pakendi suurus 2 brutokaal (kg) | 1.23 |
| Pakendi suurus 3 (ülekaal) | 6 |
| Pakendi suurus 3 pikkus (mm) | 368 |
| Pakendi suurus 3 laius (mm) | 321 |
| Pakendi suurus 3 kõrgus (mm) | 214 |
| Pakendi suurus 3 brutokaal (kg) | 7.748 |
| Pakendi suurus 4 (kaubaalus) | 200 |
| Pakendi suurus 4 pikkus (mm) | 1200 |
| Pakendi suurus 4 laius (mm) | 800 |
| Pakendi suurus 4 kõrgus (mm) | 1006 |
| Pakendi suurus 4 brutokaal (kg) | 208.952 |
| Kasutusjuhend (eng) | Laadige alla siit |
| CE vastavusdeklaratsioon | Laadige alla siit |
